Hot Stamping and Die Cutting Machine

Product name : Hot Stamping and Die Cutting Machine

Product No. : TYMC-1100

Monthly Output :

Quality Garantee : One year

Terms of Payment : TT,LC at sight

Installation&Training :

←[Previous Product]

Online Inquiry

Email Us

Details:

Hot foil stamping machine is suitable for thermo printing of various cigarette cases, wine boxes, cosmetics boxes, medicine boxes, photos, business cards, greeting cards,etc
The reduction gear shaft is made of hardened high quality alloy-steel. Lubricated counter- pressure elements prevent the gears from deviating.

Main Technical Parameters:

Max. inside chase size (mm)	1100×800	Zones individually heated	6
Max. stamping size (mm)	1100	Groups of feeding foil	3
Speed (sheets/min)	27±2	Motor power (kw)	5.5
Max. foil advance (mm)	800	Machine Weight(kg)	5500
Heating capacity(kw)	14	Flat regulating distance(mm)	26±6
Machine dimensions(mm)	2080×1950×2230

Features and Advantages:

1. High strength due to one piece casting by using top-ranking material for machine body.

2. The bearing adopts high quality copper alloy with strong bearing capacity and good resistance.

3. TYMC hot foil stamping machine is very versatile, with the functions of hot stamping,die cutting and

concave-convex forming.

4. The display system with touch screen greatly improves the productivity.

5. This machine adopts imported PLC microcomputer control, stepper motor drive for reliable operation and

convenient adjustment .

6. Electrical system is with reasonable design and high safety .
7. Zones individually heated by 6 zones with separate automatic constant temperature control.

8. With continuous hot stamping, hot stamping foil stamping closed open delay,delay time can be adjusted.

9. Safety protection is designed according to CE standard.

10. Automatic oil feeding.

11. Stainless steel board.

Electric parts:

1.CHINT circuit breaker(China brand) 2.CHINT AC contactor(China brand)

3.Onpow Button switch 4.Schneider fuse switch

5.OMRON photoelectric switch 6.Xinjie PLC Touch Screen(China

7.Taiwan Mingwei power switch

More Pictures:
